Upgrading your vehicle’s exhaust tip is one of the easiest ways to enhance both its appearance and sound. Whether you’re looking for a sleek chrome finish, an aggressive black tip, or something that adds a bit of extra growl to your ride, exhaust tips are the finishing touch your system needs.
In this guide, we’ll break down everything you need to know, including:
✔️ How to install an exhaust tip
✔️ Choosing the right size for your vehicle
✔️ Whether exhaust tips affect sound
✔️ Recommended exhaust tips from Modern Day Muffler
Let’s dive in!
How to Install Exhaust Tips
Installing an exhaust tip is a straightforward process that can be done at home with minimal tools. Whether you’re upgrading for style or a subtle sound improvement, here’s how to do it.
Tools & Materials Needed:
- Wrench or socket set – For tightening clamps or bolts
- Tape measure – To ensure a proper fit
- WD-40 or lubricant – Helps with a smooth installation
- Welder (optional) – For a permanent install
- Exhaust clamps (if applicable) – Secure bolt-on tips
Step-by-Step Installation
- Measure Your Exhaust Pipe – The inlet size of your new exhaust tip should match your existing exhaust pipe’s outlet. []
- Clean the Pipe – Remove any dirt, rust, or buildup to ensure a secure fit.
-
Slide on the Exhaust Tip – Depending on the type, you may need to clamp, bolt, or weld the tip.
- Bolt-On Tips: Align the tip and tighten the screws evenly.
- Clamp-On Tips: Slide the tip over the exhaust and tighten the provided clamps.
- Weld-On Tips: Spot weld to secure, then fully weld around the connection.
- Adjust & Align – Ensure the tip is centered and positioned correctly.
- Secure It – Double-check the tightness to prevent rattling or loosening over time.
What Size Exhaust Tip Do I Need?
Choosing the right exhaust tip size depends on a few factors:
Key Measurements:
📏 Inlet Diameter – The tip’s inlet should match your exhaust pipe’s outlet. (Example: If your pipe is 2.5 inches, your tip should have a 2.5-inch inlet.)
How to Measure Outside Diameter
If the pipe’s end is open, measure the distance from one inside edge to the opposite inside edge through the center using a tape measure or ruler. For greater accuracy, use dial calipers.
If the pipe’s end is not accessible, you’ll need to cut it to obtain an accurate measurement.
📏 Outlet Diameter – Determines the visual appeal. Most range between 3 to 5 inches, with larger diameters giving a more aggressive look.
How to Measure Outside Diameter
If the end of the pipe is fully exposed (not covered by an exhaust tip or inserted into a muffler), use a tape measure or ruler to determine its size. Measure from one outer edge to the opposite outer edge, passing through the center.
If the end of the pipe is obstructed, use dial calipers to measure the diameter. If calipers aren’t available, you can calculate the diameter instead. First, measure the pipe’s circumference using a tailor’s measuring tape or a piece of string (which you can then measure with a standard tape or ruler). Divide the circumference by π (3.14) to determine the outside diameter.
📏 Tip Length – Longer tips extend further from the bumper and can enhance the overall aesthetic but may cause clearance issues.
Style Considerations:
✔️ Single-wall vs. double-wall: Double-wall tips have a thicker edge for a premium look.
✔️ Angle cut vs. straight cut: Angle cut tips offer a sportier aesthetic.
✔️ Rolled-edge vs. sharp-edge: Rolled edges soften the look, while sharp edges appear more aggressive.
Do Exhaust Tips Change Sound?
While an exhaust tip alone won’t completely transform your vehicle’s sound, it can slightly modify the tone depending on its design.
How Different Tips Affect Sound:
- Larger Tips: Can amplify the existing sound slightly, making it deeper.
- Rolled Edge Tips: Create a smoother, more refined tone.
- Resonated Tips: Feature internal chambers that slightly enhance the exhaust note.
Want a Noticeable Sound Change?
For a deeper, throatier growl, pair your new exhaust tip with a performance muffler or resonator delete.
Best Exhaust Tips from Modern Day Muffler
At Modern Day Muffler, we offer high-quality Exhaust Tips Collection designed to fit various vehicle makes and models. Whether you want a simple chrome upgrade or an aggressive blacked-out look, we have the perfect tip for your ride.
Final Thoughts
Installing an exhaust tip is one of the simplest and most cost-effective ways to enhance your vehicle’s appearance and sound. Just remember to measure your exhaust pipe correctly, choose a tip that complements your car’s style, and secure it properly.
Need help choosing the right exhaust tip? Contact us! Our experts are here to help you find the perfect fit for your vehicle.
