Accel IgnitionCoil-2015-2020 HondaCivic 2.0L, 2.0L Turbo and Fit 1.5L 4-140084K
Accel IgnitionCoil-2015-2020 HondaCivic 2.0L, 2.0L Turbo and Fit 1.5L 4-140084K is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Fitment
Fitment
Warranty Information
Warranty Information
Customer service is our top priority and because we value your time and energy we ask you to visit our Contact Us page and reach out so that we may assist you in finding the correct warranty for your product. Please include your name, the name on the order, the order number, and the SKU of the product to ensure the quickest and most accurate response to your inquiry.
Description
Description
Overview:
ACCEL Coils are available for Honda 2.0L, 2.0L Turbo and 1.5L 4-Cylinders.
ACCEL Super Coils feature advanced bobbin technology, highly specialized silicon magnetic steel cores, optimized windings, proper resistance and engineered turn ratios that deliver a high performance, quality coil. Specialized high temperature epoxy resists shock and vibration, while increasing thermal conductivity. These are direct high performance replacements for OEM coils.
Features:
- Direct bolt-on replacement
- Meets or exceeds O.E. (Original Equipment) specifications
- Honda OEM (PN 30520-5R0-013)
- High temp epoxy resists shock and vibration
- Advanced bobbin technology for maximum output and performance
- OBD II compatible - will not trip a code
Application:
| Year | Make | Model | Submodel | Engine Size |
|---|---|---|---|---|
| 2016 - 2018 | Honda | Civic | LX | 122/2 L4 |
| 2016 - 2018 | Honda | Civic | EX | 122/2 L4 |
| 2016 - 2018 | Honda | Civic | DX | 122/2 L4 |
| 2016 - 2018 | Honda | Civic | LX-P | 122/2 L4 |
| 2017 - 2019 | Honda | Civic | Type R | 122/2 L4 |
| 2018 | Honda | Civic | SE | 122/2 L4 |
| 2015 - 2019 | Honda | Fit |
Specs:
| Brand | ACCEL |
|---|---|
| Color | Black |
| Emission Code | 2 |
| Inductance | 1.2 mH |
| Maximum Voltage | 50,000 Volts |
| Peak Current | 85 mA |
| Primary Resistance | 0.41 OHMs |
| Product Type | Coil |
| Quantity | Single |
| Secondary Resistance | 9.81K OHMs |
| Spark duration | 2,100 uS |
| Turns Ratio | 5.08402777777778 |
