EARLS Speed-Flex Hyperfirm Pre-Made Hose 64151514ERL
EARLS Speed-Flex Hyperfirm Pre-Made Hose 64151514ERL is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability
Fitment
Fitment
Warranty Information
Warranty Information
Customer service is our top priority and because we value your time and energy we ask you to visit our Contact Us page and reach out so that we may assist you in finding the correct warranty for your product. Please include your name, the name on the order, the order number, and the SKU of the product to ensure the quickest and most accurate response to your inquiry.
Description
Description
Overview:
Our factory assembled hoses are made from the same SPEED-FLEX stainless steel braid protected hose of extruded PTFE that is the world standard of the racing industry for flexible brake, clutch and instrument hoses. Hoses are assembled with Earl''s SPEED-FLEX crimp or swaged permanently installed hose ends. Each hose is pressure tested to 4,000 psi.
Features:
- Extruded PTFE
- Standard of Racing Industry
- Firmer Brake Feel
- For Flexible Brake & Clutch Hoses
- For Instrument Hoses
- Pressure Tested To 4000 PSI
Applications:
- Universal Fitment
- Supported Fluids: Automatic Transmission Fluid, Bio-Fuels, Brake Fluid, Coolant, Diesel, E85, Methanol/Alcohol, Oil, Pump Gas, Race Gas
Specs:
- Brand: Earl's
- Hose End 1 Size: 1/8 in NPT Male
- Hose End 2 Size: 1/8 in NPT Male
- Hose End Finish: Electroless Nickel Plated
- Hose End Material: Steel
- Hose Outer Material: Stainless Steel
- Hose Size: 4 AN
- Inside Diameter: 0.173-0.203 in
- Length: 14 in
- Max Working PSI: 2000 PSI
- Minimum Bend Radius: 1.5 in
- Outside Diameter: 0.304-0.343 in
- Product Type: Hose Assembly
- PTFE Wall Thickness: 0.040 in
- Submersible in Fuel: Yes
- Temperature Range: -65 to 450 Farenheit
- Part Number: 64151514ERL
Technical Notes:
Statement from Earl's: We have independent test lab reports on file showing that prototype assemblies exceeded D.O.T. recommendations in all categories. The only continuing test program however, is a 4000 P.S.I. hydrostatic pressure test of every hose assembly that we make. We do not claim that any individual hose assembly is certifiable to D.O.T. standards, and we therefore must advise you that they are sold for off-road applications only. We make no claim of usability or suitability for highway or road use. PTFE brake hoses must be installed by an experienced professional mechanic. After installation each hose must be clean and free flowing. There must be no possibility that the installed hose assemblies can be stretched, crimped, or kinked under any conditions of wheel travel and steering angle. As with any hose installation, periodic inspection of hose condition is essential.
