Mid-Length Headers for 70-81 GM F Body 4.8-6.2L LS Engine Swap D3358

Overview:

70-81 GM F Body LS Mid Length Silvr Coat

Mid-Length Headers, often called Clipsters, are engineered to provide superior performance gains over Manifold Replacements or Block Hugger style headers. These headers enhance your vehicles's horsepower and torque while preserving ground clearance for cars with a lowered stance and trucks where long tube headers may hang to low. This fitment is tailored for popular aftermarket engine swap kits. Doug's engine swap headers were developed to solve common fitment issues in tight spaces, making your swap process smoother. No more guesswork or modifications needed - just straightforward installations that save you time and frustration.

Features:

• 3/8" Thick machined flanges to prevent warping
• CNC mandrel bent tubes for ensuring accurate fit and optimal flow
• Heavy duty 16-gauge tubing for long life
• Tubes are pre-polished to removed scratches before applying metallic ceramic or hi-temp black coating

Specs:

• Brand: Doug's Headers
• Collector Attachment: Slip fit
• Collector Diameter: 3.0 IN
• Collector Port Diameter: 3.0 IN
• Color: Silver
• Cylinder Head Port Shape: Round
• Design: Mid Length
• EGT Port: No
• Finish: Metallic Ceramic Coated
• Flange Thickness: 0.375 IN
• Gasket Or Seal Included: Yes
• Gaskets Included: Yes
• Grade Type: Performance
• Header Material: Steel
• Header Style: Mid Length
• Material: Steel
• Mounting Hardware Included: Yes
• Oxygen Sensor Port: No
• Port Shape: Round
• Primary Tube Outside Diameter: 1.875 IN
• Primary Tubing Diameter: 1.875 IN
• Prop 65 (C, R or CR): CR
• Prop 65 Yes/No: Yes
• Sheen Level: Semi-Gloss
• Title: Doug's Mid Length Header 70-81 GM F Body 4.8-6.2L LS Engine Swap 1 7/8" Primary 3" Collector Silver Ceramic Coated D3358
• Tube Wall Thickness: 16 GU
• Part Number: D3358

Emissions:

• This Product is LEGAL for Closed Course Competition use or Pre-Emissions Controlled Vehicles ONLY. It is Not Legal for use on any Emissions Controlled Vehicle for Street or Off Highway use.

Fitment Notes:

• For use with Chevrolet LS Engine Swap.
• Use with Doug's LS Engine and Transmission Mount kits.
